Ubiquiti EdgeRouter X, 6-port Gigabit Router, 1x SFP In, pas

Preis anfragen
SKU: 121649 Kategorie:

(5) Gigabit RJ45 ports with passive PoE support
(1) Gigabit SFP port for backhaul applications
Ports configurable for line-rate, Layer-2 switching
130 kpps for 64-byte packets
1 Gbps for 1518-byte packets
Dimensions 142 x 75 x 23 mm (5.59 x 2.95 x 0.91″)
Weight 215 g (7.58 oz)
Max. Power Consumption 5W
Max. Total PoE Output 50W @ 24V
PoE Output Passive 24V (Pins 4, 5+; 7, 😎
Power Input 24VDC, 2.5A Power Adapter (Included)
Power Supply External AC/DC Adapter
Supported Voltage Range 9 to 26VDC
Button Reset
LED Power, Link/Activity (6), PoE (5)
Processor Dual-Core 880 MHz, MIPS1004Kc
System Memory 256 MB DDR3 RAM
Code Storage 256 MB NAND
Certifications CE, FCC, IC
Wall-Mount Yes
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature -10 to 45° C (14 to 113° F)
Operating Humidity 10 to 90% Noncondensing
Networking Interfaces
Data/PoE Output Port (5) 10/100/1000 RJ45 Ports
Data Port (1) 100/1000 SFP Port
PoE with 24VDC Power Adapter
PoE Out Voltage Range 22-24VDC
Max. PoE Wattage Per
Data/PoE Output Port
12W (24V)
Max. PoE Wattage Combined
(All 5 Data Ports)
PoE Method Passive

Gewicht 0,7 kg
