Electromagnetical Properties:
| Frequency range: | 5150MHz ? 5850MHz |
| VSWR: | Nominal 1.5:1, Maximal 2:1 |
| Nominal Impedance: | 50 ohm |
| Gain: | 10 dBi |
| Polarization: | Vertical or Horizontal |
| Azimuth Beamwidth (3dB): | Nominal 20° |
| Elevation Beamwidth (3dB): | Nominal 20° |
| Maximum Power: | 10 W |
Mechanical Properties:
| Enclosure: | 185mm x 185mm x 45mm |
| Connectors: | N female |
| IP Protection: | IP 67 |
| Temperature range: | from -40 °C to 80 °C |
| Wind Speed: | 160Km/h |
