Highlights:
- High quality image with 5MP, 1/2.7″CMOS sensor
- 5MP (2880*1620)@ 30/25fps; 4MP (2560*1440)@ 30/25fps; 3MP (2304*1296) @30/25fps; 2MP (1920*1080) @30/25fps
- Ultra 265, H.265, H.264, MJPEG
- LightHunter technology ensures ultra-high image quality in low illumination environment
- 120dB true WDR technology enables clear image in strong light scene
- Support 9:16 Corridor Mode
- Built-in Mic
- Smart IR, up to 40m (131ft) IR distance
- Supports 256 G Micro SD card
- IP67 protection
- Support PoE power supply
Technical Details:
| ALL-CAM2497v2-LEN | ||||
Camera | ||||
| Sensor | 1/2.7″, 5.0 megapixel, progressive scan, CMOS | |||
| Lens | 4.0mm@F1.6 | |||
| DORI Distance | Observe (m) | Recognize (m) | Identify (m) | |
| 25.2 | 12.6 | 6.3 | ||
| 36.0 | 18.0 | 9.0 | ||
| Angle of View (H) | 78.7° | |||
| Angle of View (V) | 44.9° | |||
| Angle of View (O) | 89.2° | |||
| Adjustment angle | Tilt: 0° ~ 90° | Rotate: 0° ~ 360° | ||
| Shutter | Auto/Manual, 1 ~ 1/100000s | |||
| Minimum Illumination | Colour: 0.003Lux (F1.6, AGC ON) 0Lux with IR on | |||
| Digital noise reduction | 2D/3D DNR | |||
| Day/Night | IR-cut filter with auto switch (ICR) | |||
| S/N | >56dB | |||
| IR Range | Up to 40m (131 ft) IR range | |||
| Wavelength | 850nm | |||
| IR On/Off Control | Auto/Manual | |||
| Defog | Digital Defog | |||
| WDR | 120dB | |||
Video | ||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | |||
| H.264 code profile | Baseline profile, Main profile, High profile | |||
| Frame Rate | Main Stream:5MP (2880*1620), Max 30fps; 4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; | |||
| 9:16 Corridor Mode | Supported | |||
| Video Bit Rate | 128 Kbps~16 Mbps | |||
| OSD | Up to 8 OSDs | |||
| Privacy Mask | Up to 4 areas | |||
| ROI | Up to 8 areas | |||
| Motion Detection | Up to 4 areas | |||
Image | ||||
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | |||
| Digital Noise Reduction | 2D/3D DNR | |||
| Smart IR | Supported | |||
| Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise | |||
| Dewarping | N/A | |||
| HLC | Supported | |||
| BLC | Supported | |||
Audio | ||||
| Audio Compression | G.711 | |||
| Suppression | Supported | |||
| Sampling Rate | 8KHZ | |||
Storage | ||||
| Edge Storage | Micro SD, up to 256GB | |||
| Network Storage | ANR, NAS(NFS) | |||
Network | ||||
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, SNMP | |||
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API | |||
| Client | EZStation EZView EZLive | |||
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | |||
| Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ | ||||
Interface | ||||
| Network | 1 RJ45 10M/100M Base-TX Ethernet | |||
| Built-in Mic | Supported | |||
| Certifications | ||||
| Certifications | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 | |||
General | ||||
| Power | DC 12V±25%, PoE (IEEE 802.3af) | |||
| Power consumption: Max 5.0W | ||||
| Dimensions (L × W × H) | 155.9 × 63.1 × 62.7mm (6.1” × 2.5” × 2.5”) | |||
| Net Weight | 0.425kg (0.93lb) | |||
| Material | Metal | |||
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing) | |||
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing) | |||
| Surge Protection | 2KV | |||
| Ingress Protection | IP67 | |||
| Reset Button | Supported | |||
