MikroTiK Routerboard RB912UAG-2HPnD

Preis anfragen
SKU: 115675 Kategorie:

RouterBOARD 912UAG with 600Mhz Atheros CPU, 64MB RAM, 1xGigabit LAN, USB, miniPCIe, built-in 2.4Ghz 802.11b/g/n 2×2, two chain wireless, 2xMMCX connectors, RouterOS L4


The RB912UAG-2HPnD is a very versatile device. It is a small wireless router with an integrated 2.4GHz high power wireless card and an additional miniPCIe slot for 802.11 wireless, or 3G card. The Gigabit port helps to utilize the full potential of 802.11n wireless speeds.

The integrated wireless card is capable of up to 1000mW output power. It has built in 16kV ESD protection on both the Ethernet and the MMCX ports.

Product specifications


Product code RB912UAG-2HPnD

CPU nominal frequency 600 MHz

CPU core count 1

Size of RAM 64 MB

Architecture MIPS-BE

10/100 Ethernet ports 0

10/100/1000 Ethernet ports 1

MiniPCI slots 0

MiniPCI-e slots 1

Wireless chip model AR9342-BL1A

Wireless standards 802.11b/g/n

Number of USB ports 1

Power Jack 1

802.3af support No

PoE in Yes

Voltage Monitor Yes

CPU temperature monitor No

PCB temperature monitor Yes

Dimensions 105x105mm

Operating System RouterOS

Operating temperature range -30C to +60C

License level 4

Antenna gain DBI No

Current Monitor No


SFP ports 0

SFP+ ports 0

USB slot type USB type A

Number of chains 2

Serial port None

Suggested price $79.00

Gewicht 0,124 kg
