included rackmount-kit is only for 10inch, for 19 inch use seperate Partnr. 161524 ( US-8-150RMKIT ) (8) Gigabit RJ45 Ports (2) SFP Ports Non-Blocking Throughput: 10 Gbps Switching Capacity: 20 Gbps Forwarding Rate: 14.88 Mpps Maximum Power Consumption: 150W Supports POE+ IEEE 802.3at/af and 24V Passive PoE Desktop-Mountable (Do not physically stack the US-8-150W.)
Dimensions 204 x 43 x 235 mm (8.03 x 1.69 x 9.25″) Weight 1.7 kg (3.75 lb) Total Non-Blocking Throughput 10 Gbps Switching Capacity 20 Gbps Forwarding Rate 14.88 Mpps Power Method 100-240VAC/50-60 Hz, Universal Input Power Supply AC/DC, Internal, 150W DC Certifications CE, FCC, IC ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV Operating Temperature -5 to 40° C (23 to 104° F) Operating Humidity 5 to 95% Noncondensing Shock and Vibration ETSI300-019-1.4 Standard PoE Interfaces POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) 24VDC Passive PoE (Pins 4, 5+; 7, 😎 Max. PoE+ Wattage per Port by PSE 34.2W Voltage Range 802.3at Mode 5057V Max. Passive PoE Wattage per Port 17W 24V Passive PoE Voltage Range 20-27V
